Parameter descriptions
Output signals
The output of a warning is signaled.
157 -
Warning
mask
1)
Output of warning activated in Create Warning Mask 536.
25 -
2)
1)
For linking to frequency inverter functions.
2)
For output via a digital output. Select the signal source for one of the parameters 531, 532, 533,
554. See chapter 7.6.5 "Digital outputs".
Parameter Warning 269 and Warning 356 (error environment) show the warnings
independent from the created Warning mask.
Parameter
Controller Status 275 and Controller Status 355 (error environment)
show the Controller Status independent from the created Warning mask.
7.6.5.9 Warning mask, application
626 Create Warning Mask Application
The Warning mask Application signals via a digital signal if an afore configured warning applies. The
configuration of the Warning mask Application is carried out via
Create Appl. Warning Mask 626.
Depending on the application, any number of warnings can be configured. This enables internal
and/or external control using a common output signal. The display of
Warning Application 273 is not
affected by the Warning mask.
Create Appl. Warning Mask 626
Function
0 -
No change
The configured warning mask is not changed.
2 - Activate all warnings
The warnings reports stated are linked in the warning
mask.
10 - Warning V-belt
Operation Mode 581 for V-belt monitoring signals no-
load operation of the application.
16 - Warning Service
The time remaining until service of DC-link or fan has
expired.
17 - Warning User 1
The signal set on digital input User Warning 1 1363 is
active.
18 - Warning User 2
The signal set on digital input User Warning 2 1364 is
active.
102 -
Deactivate all warnings
All warnings are deactivated.
110 -
Deactivate warning V-belt
Warning 10 is deactivated.
116 -
Deactivate warning service
Warning 16 is deactivated.
117 -
Deactivate warning User 1
Warning 17 is deactivated.
118 -
Deactivate warning User 2
Warning 18 is deactivated.
The selected warning mask application can be read out via parameter
Actual Appl. Warning Mask
627. The above operation modes of parameter Create Appl. Warning Mask 626 are encoded in the
Actual Appl. Warning Mask 627. The code is calculated by hexadecimal addition of the individual
operation modes and the corresponding abbreviation.
Warning code
Create Appl. Warning Mask 626
A 01C1 - 2 - Activate all warnings
A 0001 BELT 10 - Warning V-belt
A 0040 SERVICE 16 - Warning Service
A 0080 User 1 17 - Warning User 1
A 0100 User 2 18 - Warning User 2
