BONFIGLIOLI Agile User Manual

Options
12.4.2 230 V connection
Frequency inverter
3phase operation
Recommend-
ed line choke
Rated cur-
rent
Inductance
Power dissipa-
tion
Typ
Typ
Agile 202
kW
A
mH
W
-01 1
0.18
LCVT004 4 7.32 20
-02 1
0.25
-03 1
0.37
-05 1
0.55
-07 1
0.75
-09 1
1.1
LCVT006
6
4.88
25
-11 1
1.5
LCVT008
8
3.66
30
-13 1
2.2
LCVT010
10
2.93
30
-15 2
3.0
LCVT015
15
1.95
45
-18 2
4.0
LCVT018
18
1.63
70
-19 3
5.5
LCVT025
25
1.17
70
-21 3
7.5
LCVT034
34
0.86
85
12.4.3 3x400 V connection
Frequency inverter
Recommend-
ed line choke
Rated cur-
rent
Inductance
Power dissipa-
tion
Typ
Typ
Agile 402
kW
A
mH
W
-02 1
0.25
LCVT004 4 7.32 20
-03 1
0.37
-05 1
0.55
-07 1
0.75
-09 1
1.1
-11 1
1.5
-13 1
2.2
LCVT006
6
4.88
25
-15 2
3.0
LCVT008
8
3.66
30
-18 2
4.0
LCVT010
10
2.93
30
-19 2
5.5
LCVT015
15
1.95
45
-19 3
5.5
LCVT015
15
1.95
45
-21 3
7.5
LCVT018
18
1.63
70
-22 3
9.2
LCVT025
25
1.17
70
-23 3
11
LCVT034
34
0.86
85
298
Operating Instructions
Agile 06/2013 Line choke
