12.9.1.3
Size 2 (
3~:
3
.0 kW to
5.5
kW
; 1~:
1.5 kW to
2.2 kW
)
Valid for the following devices
Frequency inverter
Typ
e
Agile
2
02
Agile
402
Mains supply
1ph.
3ph.
3ph.
Power
kW
kW
kW
-
15
2
1.5
3.0
3.0
-
18 2
2.2
4.0
4.0
-1
9 2
--
--
5.5
Place a seal between frequency inverter and mounting plate.
Use screws M6 with minimum length 30 mm.
222
(+10)
80
56
251
205
6
222 (+10)
78
311
Assembly variants
06/201
3
Operating Instructions
Agile
310
312
