Technical data
11.3 Control electronics
Voltage output DC 24 V
Terminals
X11.1 (DC +24 V), X11.2 (DC 0 V)
Maximum output current
DC 100 mA
Voltage output DC 10 V
Terminal
X13.4
Maximum output current
DC 8.2 mA
Minimum output current
DC 2.3 mA
1
Voltage input DC 24 V
Terminal
X13.1 (DC 24 V), X13.2 (DC 0 V)
Input for external power supply.
2
Input voltage range
DC 24 V ±10%
Rated input current
Max. DC 1.0 A (typically DC 0.45 A)
Input peak current
Typically < DC 15 A (max. 100 µs)
External fuse
Standard fuse elements for rated current, characteristic: slow
Safety
Safety extra low voltage SELV according to EN 61800-5-1
Digital inputs
Terminals
X11.4, X11.5, X12.1, X12.2
Signal level
PNP
High: DC 15…24…30
V
Low: DC 0…5
V
NPN
High: DC 0…5
V
Low: DC 15…24…30
V
Maximum input voltage
DC 30 V (DC 6 mA at DC 24 V)
Input resistance
3.9 kΩ
Response time
2 ms
Other properties
PLC compatible
Digital inputs for enable and safety function STO
Terminals
X11.3, X13.3
Signal level
Low:
DC 0 … 3
V
High:
DC 15 … 30
V
Maximum input voltage
DC 30 V (DC 10 mA at DC 24 V)
Input resistance
1.8 kΩ
Response time
Enable is activated 10 ms after triggering.
Digital output
Terminal
X13.5
Output voltage
DC 22 V (DC 15 … 28 V)
Maximum output current
DC 100 mA
3
Other properties
Overload and short-circuit proof, overvoltage-protected
1
Depending on value at 24 VDC voltage input.
2
Connect ground (GND) of external power supply to terminal X13.2 (GND).
3
The value is reduced if additional control outputs are used.
286
Operating Instructions
Agile 06/2013 Control electronics
