BONFIGLIOLI Agile User Manual

Technical data
Digital input/output
Terminal
X11.6
Digital Input
Signal level
PNP
High: DC 15…24…30
V
Low: DC 0…5
V
NPN
High: DC 0…5
V
Low: DC 15…24…30
V
Maximum input voltage
DC 30 V (DC 6 mA at 24 V)
Input resistance
3.9 kΩ
Response time
2 ms
Other properties
PLC compatible
Digital output
Output voltage
DC 24 V (DC 15 … 30 V**)
Maximum output current
DC 100 mA*
Other properties
Overload and short-circuit proof, overvoltage-protected
Multifunction inputs (digital/analog input)
Terminal
X12.3, X12.4
Digital Input
Signal level
PNP
High: DC 15…24…30
(digital)
V
Low: DC 0…5
(digital)
V
NPN
High: DC 0…5
(digital)
V
Low: DC 15…24…30
(digital)
V
Maximum input voltage
DC 30 V (DC 6 mA at DC 24 V)
Input resistance
3.9 kΩ
Response time
2 ms
Other properties
PLC compatible
Voltage input (analog)
Input voltage
DC 0 … 10 V
Input resistance
78 kΩ
Resolution
10 Bit
Current input (analog)
Input current
DC 0 … 20 mA
Input resistance
250 Ω
Resolution
9 Bit
Multifunction output (digital/analog/frequency/pulse train output)
Terminal
X13.6
Digital output
Output voltage
DC 24 V (DC 15 … 30 V**)
Maximum output current
DC 100 mA
Other properties
Overload and short-circuit proof, overvoltage-protected
Analog output (PWM)
Output voltage
DC 24 V (DC 15 … 30 V**)
Maximum output current
DC 100 mA*
Other properties
Pulse-width modulated signal f
PWM
= 126 Hz
Frequency output
Output voltage
DC 24 V (15 … 30 V**)
Maximum output current
DC 100 mA
Maximum output frequency
150 kHz
Other properties
Pulse train output
Output voltage
DC 24 V
Maximum output current
DC 100 mA*
Maximum output frequency
150 kHz
*
The maximum output current of an output of 100 mA is reduced if additional control out-
puts are used.
**
Dependent on the voltage supply of the control unit and the connected load on the differ-
ent outputs. Maximum guaranteed value: 15 VDC.
287
Control electronics 06/2013 Operating Instructions
