BONFIGLIOLI Agile

Parameter descriptions
3-wire control is activated with parameter Local/Remote 412:
Local/Remote 412
Function
5 - Control 3-wire
Control of direction of rotation (parameter Start Clockwise 68, Start
Anticlockwise
69) and signal
Start 3-Wire Ctrl
87 via digital inputs.
See chapter 7.3.1 "Control" for further operation modes of parameter Local/Remote 412.
Parameter
Factory setting
Start 3-Wire Ctrl 87
7 - Off
7.6.6.4 Motor potentiometer
62 Frequency Motorpoti Up
63 Frequency Motorpoti Down
The reference frequency of the drive can be set via digital control signals. See chapter 7.5.3.3.1
"Control via reference frequency channel".
Parameter
Factory setting
Frequency Motorpoti Up 62
7 - Off
Frequency Motorpoti Down 63
7 - Off
72 Percent Motorpoti Up
73 Percent Motorpoti Down
The reference percentage can be set via digital control signals. See chapter 7.5.3.3.2 "Control via
reference percentage channel".
Paramete
Factory setting
Percent Motorpoti Up 62
7 - Off
Percent Motorpoti Down 63
7 - Off
7.6.6.5 Fixed frequency changeover
66 Fixed Frequency Change-Over 1
67 Fixed Frequency Change-Over 2
131 Fixed Frequency Change-Over 3
By combining the logic states of the fixed frequency changeover modes 1, 2 and 3, the fixed frequen-
cies 1 to 8 (parameters 480 to 488) can be selected. See chapter 7.5.1.3 "Fixed frequencies".
Parameter
Factory setting
Fixed Frequency Change-Over 1 66
74 - IN4D
Fixed Frequency Change-Over 2 67
7 - Off
Fixed Frequency Change-Over 3 131
7 - Off
7.6.6.6 Fixed percentage changeover
75 Fixed Percent Change-Over 1
76 Fixed Percent Change-Over 2
By combining the logic states of Fixed Percent Change-Over 1 75and Fixed Percent Change-Over 2
76, the fixed percentages 1 to 4 (Parameters 520 to 523) can be selected. See chapter 7.5.2.3 "Fixed
percentages".
Parameter
Factory setting
Fixed Percent Change-Over 1 75
7 - Off
Fixed Percent Change-Over 2 76
7 - Off
201
