Options
12.3.1 230 V devices
The following table shows the cross reference of brake resistors, that can be used for a majority of
applications.
The column “Percentage duty cycle” shows, how long inside a duty cycle the brake resistor can be
operated with nominal power.
Frequency inverter
Recommended
brake resistor
Power at percentage duty cycle,
cycle time 120 s
Type
1ph.
3ph.
Type
Percentage duty cycle
Agile 202
kW
kW
% (1ph.)
% (3ph.)
-01 1
0,09
0,18
BR 160/100
100
89
-02 1
0,12
0,25
BR 160/100
100
64
-03 1
0,18
0,37
BR 160/100
89
43
-05 1
0,25
0,55
BR 160/100
64
29
-07 1
0,37
0,75
BR 160/100
43
21
-09 1
0,55
1,1
BR 160/100
29
15
-11 1
0,75
1,5
BR 432/37
57
29
-13 1
1,1
--
BR 432/37
39
--
--
2,2
BR 432/37
--
20
-15 2
1,5
3,0
BR 432/37
29
14
-18 2
2,2
4,0
BR 432/37
20
11
-19 3
3,0
5,5
BR 667/24
22
12
-21 3
3,0
--
BR 667/24
22
--
--
7,5
2x BR 432/37
1)
--
11
1) 2x BR432/37 parallel
For the connection of a brake resistor refer to chapter 5.6.5 “Brake resistor”.
12.3.2 400 V devices
The following table shows the cross reference of brake resistors, that can be used for a majority of
applications.
The column “Percentage duty cycle” shows, how long inside a duty cycle the brake resistor can be
operated with nominal power.
Frequency inverter
Recommended
brake resistor
Power at percentage duty cycle,
cycle time 120 s
Type
Type
Percentage duty cycle
Agile 402
kW
BR 213/300
%
-02 2
0,25
BR 213/300
85
-03 2
0,37
BR 213/300
58
-05 2
0,55
BR 213/300
39
-07 2
0,75
BR 213/300
28
-09 2
1,1
BR 213/300
19
-11 2
1,5
BR 213/300
14
-13 2
2,2
BR 213/300
10
-15 2
3,0
BR 471/136
16
-18 2
4,0
BR 471/136
12
-19 2
5,5
BR 471/136
1)
9
-19 2
5,5
BR 1330/48
24
-21 2
7,5
BR 1330/48
18
-22 2
9,2
BR 1330/48
14
-23 2
11
BR 1330/48
12
1) the maximum breaking power of this combination is limited to 4,4kW
For the connection of a brake resistor refer to chapter 5.6.5 “Brake resistor”.
