BONFIGLIOLI Agile User Manual

Error protocol
13.1.1 Error messages
259 Actual Error
Parameter
Actual Error 259 shows the error code.
Error code
Error messages
Code
Meaning
F00 00 No fault has occurred.
Overload
F01
00 Frequency inverter overloaded, check load behaviour. Reduce ramps and speed.
01 Frequency inverter overloaded in low output frequency range.
02 Frequency inverter overloaded (60 s), check load behaviour.
03 Short-term overload (1 s), check motor and application parameters.
Heat Sink
F02
00 Heat sink temperature too high, check cooling and ventilator.
01 Heat sink temperature too cold, check allowed ambient temperature.
Inside
F03
00 Inside temperature too high, check cooling and ventilator.
01
Inside temperature too cold, check allowed ambient temperature.
03
Capacitor temperature too high, check cooling and ventilator.
Motor connection
F04
00 Motor temperature too high or sensor defective, check connection at terminal X12.4.
01 Motor circuit breaker tripped, check drive.
02 V-belt monitoring reports no load on the drive.
03 Phase failure, check motor and wiring.
Output current
F05
00 Overloaded, check load situation and ramps.
06 Motor phase current too high, check motor and wiring.
07 Message from phase monitoring, check motor and wiring.
08 Message from phase monitoring, check motor and wiring.
09 Message from phase monitoring, check motor and wiring.
11
Motor still rotates. The motor is still excited and rotates and
− drive start command applies and the flying start function is deactivated or
− a device test is tried to start
Internal Error.
F06
xx
Internal Error. Please contact your Bonfiglioli office.
DC–link voltage
F07
00 DC link voltage too high, check deceleration ramps and connected brake resistor.
01 DC link voltage too small, check mains voltage.
02 Power failure, check mains voltage and circuit.
03 Phase failure mains, check mains fuses and circuit.
04
Reference DC-Link Limitation
680 too small, check mains voltage.
05
Overvoltage brake chopper. Refer to chapter 13.3 “Troubleshooting” (Shut-down).
06
Overvoltage motor chopper. Refer to chapter
13.3 “Troubleshooting” (Shut-down).
Electronics voltage
F08
01 Electronics voltage DC 24 V too low, check control terminal.
04 Electronics voltage too high, check wiring of control terminals.
05
Fault in the the A/D converter. Remove all external connections (signal terminals etc.)
and check if the fault remains
326
Operating Instructions
Agile 06/2013 Error list
