BONFIGLIOLI Agile User Manual

Actual values
9 Actual values
The various control functions and methods include electrical control variables and various calculated
actual values of the machine or system. The different actual values can be read out for operational
and error diagnosis via a communication interface or in the "Actual" menu of the operator panel.
9.1 Actual values of frequency inverter
Actual values of frequency inverter
No.
Description
Function
222
DC–link voltage
Direct voltage in DC-link.
223 Modulation
Output voltage of the frequency inverter relative to the mains
voltage (100% = U
FIN
).
228
Internal Reference Fre-
quency
Total of Reference frequency source 1 475 and Reference fre-
quency source 2
492.
229 Reference percentage
Total of Reference percentage source 1 476 and Reference
percentage source 2 494 as reference value of the reference
percentage channel.
230
Actual percentage value
Actual value signal at the Actual percentage source 478.
243 Digital Inputs (Hardware)
Status of digital inputs in decimally encoded form:
− of enable signal (STOA AND STOB)
− of the six digital inputs
− of multifunction input 1 in setting
Operation mode MFI1
452 "3 - digital NPN (active: 0 V)" or "4 - digital PNP (ac-
tive: 24 V)".
− of multifunction input 2 in setting
Operation mode MFI2
562 "3 - digital NPN (active: 0 V)" or "4 - digital PNP (ac-
tive: 24 V)".
− of digital input/output in setting
Operation mode terminal
X11.6
558 = "0 - input IN3D".
Represents the status of the physical inputs (also refer to actual
value Digital inputs 250).
244 Working hours counter
Operating hours in which the output stage of the inverter is
active.
245 Operation hours counter
Operating hours of the frequency inverter in which supply volt-
age is available.
246 Capacitor temperature
Measured capacitor temperature. Warning or shutdown if tem-
perature is too high.
249 Active data set
According to Data set change-Over 1 70 and Data set change-
Over 2 71 of the data set currently used.
250 Digital inputs
Status of digital inputs in decimally encoded form:
− of enable signal (STOA AND STOB)
− of the six digital inputs
− of multifunction input 1 in setting
Operation mode MFI1
452 "3 - digital NPN (active: 0 V)" or "4 - digital PNP (ac-
tive: 24 V)".
− of multifunction input 2 in setting
Operation mode MFI2
562 "3 - digital NPN (active: 0 V)" or "4 - digital PNP (ac-
tive: 24 V)".
− of digital input/output (terminal X11.6) in setting
Operation
mode terminal X11.6
558 = "0 - input IN3D".
251 Analog input MFI1A
Input signal at multifunction input 1. Via parameter Operation
mode MFI1 452, multifunction input 1 must be set up as a
voltage or current input.
265
Actual values of frequency inverter 06/2013 Operating Instructions
