Actual values
Actual values of frequency inverter
252 Repetition frequency input
Signal on repetition frequency input according to Operation
mode IN2D
496.
253 Analog input MFI2A
Input signal at multifunction input 2. Via parameter Operation
mode MFI2 562, multifunction input 2 must be set up as a
voltage or current input.
254 Digital outputs
Status of digital outputs in decimally encoded form:
− of digital output OUT1D
− of multifunction output in setting
Operation mode MFO1
(X13.6)
550 = "1 - Digital MFO1D"
− of digital input/output in setting
Operation modeterminal
X11.6
558 = "1 - output OUT3D".
− of relay output
255 Heat sink temperature
Measured heat sink temperature. Warning or shutdown if tem-
perature is too high.
256 Inside temperature
Measured inside temperature. Warning or shutdown if tempera-
ture is too high.
257 Analog output MFO1A
Output signal at multifunction output 1 in setting Operation
mode MFO1 (X13.6) 550 = "10 - Analog (PWM) MFO1A"
258 PWM input
Pulse-width modulated signal at PWM input according to Op-
eration mode IN2D 496.
259 Actual Error
Error message with error code and abbreviation. See chapter
13.1.1 "Error messages".
269 Warnings
Warning message with warning code and abbreviation.
Please note: Warnings 269 is not affected by Create warning
273 Application Warnings
Warning message application with warning code and abbrevia-
tion. Please note: Warnings Application 273 is not affected by
626.
275 Controller Status
The reference value signal is limited by the controller coded in
the controller status.
277 STO Status
Signal status of digital inputs A (STOA) and B (STOB) for ena-
ble.
278 Frequency MFO1F
Output signal at multifunction output in setting Operation mode
MFO1 (X13.6) 550 = "20 - repetition frequency (FF) MFO1F"
or "30 - Pulse Train (PT) MFO1F".
282 Reference bus frequency Reference value from serial interface.
283 Reference ramp frequency Reference value from reference frequency channel.
470 Revolutions Actual value of position distance of positioning operation.
1530 Service Interval DC-link
The time remaining until next service in percent of maintenance
interval. If a value of 0% is displayed, service is required. It
must also be checked if a component must be replaced. Refer
to chapter 10.3.1 “DC-link”.
1531 Service Interval Fan
The time remaining until next service in percent of maintenance
interval. If a value of 0% is displayed, service is required. It
must also be checked if a component must be replaced. Refer
to chapter
10.3.2 “Fan”.
1533 Maintenance Note
Service status. Refer to chapter 10.3 “Monitoring of service
interval”.
Service of device test. Refer to chapter
7.2.3 “Device test”.
The actual values can be read out and monitored in the "Actual" menu of the operator
panel.
