BONFIGLIOLI Agile User Manual

Parameter descriptions
Output signals
The output of a warning is signaled.
215 -
Warning
mask, appli-
cation
1)
Output of warning activated in Create Appl. Warning Mask 626.
27 -
2)
1)
For linking to frequency inverter functions.
2)
For output via a digital output. Select the signal source for one of the parameters 531, 532, 533,
554. See chapter 7.6.5 "Digital outputs".
Parameter Warning Application 273 shows the Application Warnings independent
from the created Warning mask.
7.6.6 Digital inputs
The assignment of the control signals to the available software functions can be adapted to the appli-
cation in question. In addition to the available digital control inputs, further internal logic signals are
available as sources.
Each of the individual software functions is assigned to the various signal sources via parameterizable
inputs. This enables a flexible use of the digital control signals.
559 Digital inputs PNP/NPN
Via parameter
Digital inputs PNP/NPN 559, the evaluation at the digital inputs can be selected as
PNP (high-switching) or NPN (low-switching).
Terminal
Digital inputs PNP/NPN 559
Function
X11.4
X11.5
X11.6
X12.1
X12.2
0 - NPN (active: 0 V)
Digital input NPN. Low-switching (with negative sig-
nal).
1 - PNP (active: 24 V)
Digital input PNP. High-switching (with positive sig-
nal). Factory setting.
In order to use multifunction input MFI1 as a digital input, setting 3 or 4 must be selected for parame-
ter
Operation Mode MFI1 452.
Terminal
Operation Mode MFI1 452
Function
X12.3
3 -
Digital NPN (active: 0 V)
Low-switching (with negative signal).
4 -
Digital PNP (active: 24 V)
High-switching (with positive signal).
In order to use multifunction input MFI2 as a digital input, setting 3 or 4 must be selected for parame-
ter
Operation Mode MFI2 562.
Terminal
Operation Mode MFI2 562
Function
X12.4
3 - Digital NPN (active: 0 V)
Low-switching (with negative signal). Factory
setting.
4 -
Digital PNP (active: 24 V)
High-switching (with positive signal).
In order to use the digital input/output (terminal X11.6) as a digital input, setting "0 - Input IN3D"
must be selected for parameter
Operation Mode Terminal X11.6 558.
Terminal
Operation Mode Terminal X11.6 558
Function
X11.6 0 - Input IN3D
The digital input/output is set as digital in-
put. Factory setting.
For setting of X11.6 as digital output, refer to chapter 7.6.4 “Digital input/output IN3D/OUT3D”.
196
Operating Instructions
Agile 06/2013 Control inputs and outputs
