Actual values
236 Torque-Forming Voltage
Voltage component of the field-orientated control forming the
torque.
238 Absolute Flux Value
Magnetic flux calculated according to the rated values and the oper-
ating point of the motor.
239 Reactive Current
Reactive current calculated from the rated motor parameters, the
control variables and the current.
Measured or calculated speed of drive.
Measured or calculated frequency of drive.
The actual values can be read out and monitored in the "Actual" menu of the operator
panel.
9.3 Actual values of the system
The calculation of the actual figures of the system is based on the parameterized system data. Specif-
ic to the application, the parameters are calculated from the fac
-t
ors, electrical variables and the con-
trols. The correct display of the actual figures is a function of the parameterized data of the system.
9.3.1 Actual system value
The drive can be monitored via the actual value Actual system value 242. See chapter 7.10.9 "System
data".
No. Description Function
242 Actual System Value Calculated actual value of drive.
9.4 Actual value memory
The assessment of the operating behavior and the service of the frequency inverter in the application
are facilitated by storing various actual values. The actual value memory guarantees monitoring of the
individual variables for a definable period. The parameters of the actual value memory can be read
out via a communication interface and displayed via the operator panel. In addition, the operator
panel enables monitoring of the peak and mean values in the "Actual" menu branch.
231 Peak Value Long Term Ixt Utilization of the device-dependent overload of 60 seconds.
232 Peak Value Short Term Ixt Utilization of the device-dependent overload of 1 second.
287 Peak Value Vdc The maximum DC link voltage measured.
288 Average Value Vdc
The mean DC link voltage calculated in the period of observa-
tion.
289 Peak Value Heat Sink Temp.
The highest measured heat sink temperature of the frequency
inverter.
290
Average Value Heat Sink
Temp.
The mean heat sink temperature calculated in the period of
observation.
291
Peak Value Inside Tempera-
ture
The maximum measured inside temperature in the frequency
inverter.
292
Average Value Inside Tem-
perature
The mean inside temperature calculated in the pe-riod of ob-
servation.
293 Peak Value Iabs.
The highest abs. current calculated from the measured motor
phases.
294 Average Value Iabs The mean abs. current calculated in the period of observation.
268
Operating Instructions
Agile
06/2013 Actual values of the system
