Actual values
Actual value memory
No.
Description
Function
295 Peak Value Active Power pos. Calculated maximum active power in motor operation.
296
Peak Value Active Power
neg.
Calculated maximum active power in generator operation.
297 Average Value Active Power The mean active power calculated in the period of observation.
298 Peak Value Capacitor Temp. Maximum measured capacitor temperature.
299
Average Value Capacitor
Temp.
The mean capacitor temperature calculated in the period of
observation.
301 Energy, positive The calculated energy to the motor in motor operation.
302 Energy, negative The calculated energy from the motor in generator operation.
The actual values can be read out and monitored in the "Actual" menu of the operator
panel.
237 Reset Memory
Parameter
Reset Memory 237 in menu "Para" of the operator panel enables resetting of the mean
and peak values. The mean value and the peak value are reset to zero.
Reset Memory 237
Function
0 - No Reset Values of actual value memory remain unchanged.
10 - Peak value long-term Ixt
Reset
Peak Value Long Term Ixt 231
.
12 - Peak value short-term Ixt
Reset Peak Value Short Term Ixt 232.
20 - Peak value Vdc
Reset Peak Value Vdc 287.
21 - Average Value Vdc
Reset Average Value Vdc 288.
30 -
Peak value Tc
Reset Peak Value Heat Sink Temp. 289.
31 -
Average Value Tc
Reset Average Value Heat Sink Temp. 290.
32 -
Peak value Ti
Reset Peak Value Inside Temperature 291.
33 -
Average Value Ti
Reset Average Value Inside Temperature 292.
34 -
Peak Value Capacitor
Temp.
Reset Peak Value Capacitor Temp. 298.
35 -
Average Value Capacitor
Temp.
Reset Average Value Capacitor Temp. 299.
40 - Peak value Iabs.
Reset
Peak Value Iabs
293.
41 -
Average value Iabs
Reset
Average Value Iabs.
294.
50 - Peak value Pactive pos.
Reset
Peak Value Active Power pos.
295.
52 - Peak value Pactive neg.
Reset
Peak Value Active Power neg.
296.
53 - Average value Pactive
Reset
Average Value Active Power 297
.
54 - Energy, positive
Reset
Energy, positive 301
.
56 - Energy, negative
Reset
Energy, negative 302
.
100 - All peak values Reset all saved peak values.
101 - All average values Reset all saved average values.
102 - All values Reset whole actual value memory.
269
Actual value memory 06/2013 Operating Instructions
