BONFIGLIOLI Agile User Manual

Technical data
11.2.1 AGL202 (3~:0.18 to 0.55 kW, 1~:0.09 to 0.25 kW, 230 V)
Type
230 V
Agile 202
-01
-02
-03
-05
Size
1
Output motor side
Selected Mains supply
1ph
3ph
1ph
3ph
1ph
3ph
1ph
3ph
Recommended
motor shaft power
P kW 0.09 0.18 0.12 0.25 0.18 0.37 0.25 0.55
Output current
I
A
0.8
1.3
1.0
1.5
1.3
2.0
1.5
3.0
Long-term
overload current (60 s)
I A 1.2 2 1.5 2.25 1.95 3.0 2.25 4.5
Short-time
overload current (1 s)
I A 1.6 2.6 2.0 3 2.6 4.0 3.0 6.0
Switching frequency
f
kHz
2, 4, 8, 16
Output, brake resistor
Minimum brake resistor
R
Ω
100
100
100
100
100
100
100
100
Recommended brake resistor
(385 V)
R Ω 300 220 250 200 220 140 200 100
Input mains side
Rated current
I
A
1.7
1.2
1.9
1.4
2.5
2.0
3.0
2.5
Maximum mains current
1)
I
A
2.5
2.2
2.9
2.5
3.6
3.3
4.2
4.0
Fuses
I
A
6
6
6
6
6
6
6
6
Fuses UL type
I
A
Bussmann FWP-10A14Fa
Mechanics
Dimensions
2)
HxWxD
mm
200 x 60 x 170
Weight (approx.)
m
kg
1.1
Degree of protection
-
-
IP20 (EN60529)
Terminals A mm
2
Mains and motor
terminals:
0.2 … 4 (flexible with sleeve)
0.2 … 6 (rigid)
Terminals relay out-
put:
0.1 … 1.5
Installation
-
-
vertical
Interior fan
-
-
no
Heat sink fan
-
-
no
Ambient conditions
Power dissipation (2 kHz
switching frequency)
P W 12 12 19 19 29 29 42 42
1) According to DIN EN 61800-5-1.
2) Dimensions of the basic device. Comply with the notes of the assembly variants in chapter 4.2
“Installation” for the standard assembly and chapter 12.9 “Assembly variants”.
