Parameter descriptions
7.5.3.4 Keypad motorpoti: Control via operator panel
For the parameterization of the control of the motor potentiometer via operator panel, it has to be
checked if the motor potentiometer is used as frequency reference value or percentage reference
value.
Depending on the parameter settings and how the function is used, it can happen that
the first
actuation of the key doesn’t cause a visible reaction.
In this case the first
ac
tuation activates the function.
7.5.3.4.1 Control via reference frequency channel
The reference frequency of the drive can be set via the operator panel in menu "Local"/"Poti F".
The reference frequency is increased or decreased via the arrow buttons.
− Button ▲: The reference frequency increases at the set value of
Ramp Frequency-Motorpoti 473.
− Button ▼: The reference frequency decreases at the set value of
Ramp Frequency-Motorpoti 473.
− Button ▲ pressed briefly: The reference frequency is increased by 0.1 Hz each time the button is
pressed.
− Button ▼ pressed briefly: The reference frequency is reduced by 0.1 Hz each time the button is
pressed.
Press the buttons briefly to fine-tune the reference frequency.
Keypad motor
potentiometer
Function
– – The reference frequency does not change.
â–²
–
The reference frequency increases at the set ramp.
Pressed briefly: Reference frequency increases by 0.1 Hz.
–
â–¼
The reference frequency decreases at the set ramp.
Pressed briefly: Reference frequency decreases by 0.1 Hz.
â–² + â–¼
The reference frequency is reset to its initial value.
WARNING
If a negative reference value is set, the drive is accelerated by pressing the button â–¼.
The reference value is increased in negative direction.
Limit
The reference values are limited via parameters
Minimum Frequency 418 and Maximum Frequen-
cy
419.
Direction of rotation reversal
If parameter
Minimum Frequency 418 is set to zero, the direction of rotation of the drive can be re-
versed via the motorpoti function.
NOTE
In order to be able to select menu "Poti F" on the operator panel, Reference Frequency
Source 1 475 or Reference Frequency Source 2 492 must be set to "5 - Keypad-
Motorpot.". By default,
Reference Frequency Source 2 492 is set to "5 - Keypad-
Motorpot.".
160
Operating Instructions
Agile
06/2013 Reference Values
