BONFIGLIOLI Agile User Manual

Parameter descriptions
Create warning mask 536
Function
39 -
Activate Warning Contr. In-
tel. Curr. Lim. LT-Ixt
Overload limit of the long-term Ixt (60 s) reached, intelligent
current limits active.
40 -
Activate Warning Contr. In-
tel. Curr. Lim. ST-Ixt
Overload limit of the short-term Ixt (1 s) reached, intelligent
current limits active.
41 -
Activate Warning Contr. In-
tel. Curr. Lim. Tc
Max. heat sink temperature T
K
reached, Operation Mode 573
for intelligent current limits active.
42 -
Activate Warning Contr. In-
tel. Curr. Lim. Motor Temp.
Max. motor temperature T
PTC
reached, Operation Mode 573
for intelligent current limits active.
43 -
Activate Warning Controller
Freq. Limitation
Reference frequency reached the Maximum Frequency 419.
The frequency limitation is active.
101 to 143
Deactivation of the operation mode within the warning mask.
The selected warning mask can be read out via parameter
Actual Warning Mask 537. The above
operation modes of parameter
Create Warning Mask 536 are encoded in the Actual Warning Mask
537. The code is calculated by hexadecimal addition of the individual operation modes and the corre-
sponding abbreviation.
Warning code
Create Warning Mask 536
A FFFF FFFF - 1 - Activate everything
A 0000 FFFF - 2 - Activate all warnings
A FFFF 0000 - 3 - Activate all controller states
A 0000 0001 Ixt 10 - Warning Ixt
A 0000 0002 IxtSt 11 - Warning short-term Ixt
A 0000 0004 IxtLt 12 - Warning long-term Ixt
A 0000 0008 Tc 13 - Warning heat sink temperature
A
0000
0010
Ti
14 -
Warning inside temperature
A
0000
0020
Lim
15 -
Warning limit
A
0000
0040
INIT
16 -
Warning Init
A
0000
0080
MTemp
17 -
Motor temperature warning
A
0000
0100
Mains
18 -
Warning mains failure
A
0000
0200
PMS
19 -
Warning motor circuit breaker
A 0000 0400 Flim 20 - Warning Fmax
A 0000 0800 A1 21 - Warning analog input MFI1A
A 0000 1000 A2 22 - Warning analog input MFI2A
A 0000 2000 Sysbus 23 - Warning system bus
A
0000
4000
UDC
24 -
Warning Udc
A 0000 8000 WARN2 25 - Warning, application
A 0001 0000 UDdyn 30 - Controller Udc dynamic operation
A 0002 0000 UDstop 31 - Controller shutdown
A 0004 0000 UDctr 32 - Controller mains failure
A 0008 0000 UDlim 33 - Controller Udc limitation
A 0010 0000 Boost 34 - Controller voltage pre-control
A 0020 0000 Ilim 35 - Controller I abs
A 0040 0000 Tlim 36 - Controller torque limitation
A 0080 0000 Tctr 37 - Controller torque control
A
0100
0000
Rstp
38 -
Ramp stop
A
0200
0000
IxtLtlim
39 -
Contr. intel. curr. lim. LT-Ixt
A
0400
0000
IxtStlim
40 -
Contr. intel. curr. lim. ST-Ixt
A
0800
0000
Tclim
41 -
Contr. intel. curr. lim. Tc
A
1000
0000
MtempLim
42 -
Contr. intel. curr. lim. motor temp.
A
2000
0000
Flim
43 -
Controller Freq. Limitation
194
Operating Instructions
Agile 06/2013 Control inputs and outputs
