BONFIGLIOLI Agile User Manual

Parameter descriptions
Create warning mask 536
Function
0 -
No change
Configured warning mask is not modified.
1 - Activate everything
The warnings and controller status messages stated are linked
in the warning mask.
2 - Activate all Warnings The warnings reports stated are linked in the warning mask.
3 - Activate all controller states
The controller status reports stated are linked in the warning
mask.
10 -
Activate Warning Ixt
The frequency inverter is overloaded
11 -
Activate Warning short-term
Ixt
Overload reserve for 1 s minus the Warning limit short-term
Ixt
405 has been reached.
12 -
Activate Warning long-term
Ixt
Overload reserve for 60 s minus the Warning limit long-term
Ixt
406 has been reached.
13 -
Activate Warning heat sink
temperature
Max. heat sink temperature T
K
minus the Warning limit heat
sink temp.
407 reached.
14 -
Activate Warning inside tem-
perature
Max. inside temperature T
K
minus the Warning limit inside
temp.
408 reached.
15 - Activate Warning limit
The controller stated in Controller Status 275 limits the refer-
ence value.
16 - Activate Warning Init Frequency inverter is being initialized
17 -
Activate Warning Motor
Temperature
Warning behavior according to parameterized Operation
Mode Motor Temp. 570 at maximum motor temperature T
PTC.
18 -
Activate Warning Mains Fail-
ure
Phase Supervision 576 reports a phase failure.
19 -
Activate Warning Motor Pro-
tective Switch
Operation Mode 571 for motor circuit breaker triggered.
20 - Activate Warning Fmax
The Maximum Frequency 419 was exceeded. The frequency
limitation is active
21 -
Activate Warning analog
input MFI1A
The input signal at analog input MFI1A is less than 1 V/2 mA
in accordance with operation mode
Error/Warning Behaviour 453.
22 -
Activate Warning analog
input MFI2A
The input signal at analog input MFI2A is less than 1 V/2 mA
in accordance with operation mode
Error/Warning Behaviour 563.
23 -
Activate Warnings system
bus
A slave on the system bus signals an error.
24 - Activate Warning Udc
The DC link voltage has reached the type-dependent mini-
mum value.
25 -
Activate Application Warning
A warning application is signaled.
30 -
Activate Warning Controller
Udc Dynamic Operation
Controller is active according to Operation Mode 670.
31 -
Activate Warning Controller
Shutdown
The output frequency in the case of a power failure is below
the Shutdown Threshold 675.
32 -
Activate Warning Controller
Mains Failure
Failure of the mains voltage and power regulation active ac-
cording to Operation Mode 670 for the voltage controller.
33 -
Activate Warning Controller
Udc Limitation
The DC link voltage has exceeded the Reference DC-Link
Limitation 680.
34 -
Activate Warning Controller
Voltage Pre-Control
The Dyn. Voltage Pre-Control 605 accelerates the control
characteristics.
35 -
Activate Warning Controller I
abs.
The output current is limited.
36 -
Activate Warning Controller
Torque Limitation
The output power or the torque is limited by the speed con-
troller.
37 -
Activate Warning Controller
Torque Control
Switch-over of field-orientated control between speed and
torque-controlled control method.
38 - Activate Warning Ramp Stop
The Operation Mode 620 selected in starting be-havior limits
the output current.
193
Control inputs and outputs 06/2013 Operating Instructions
