BONFIGLIOLI Agile User Manual

Commissioning
SETUP Selection 796
Function
21 -
Plaus.-Check Machine
Data, DS1
The rated motor parameters in data set 1 are checked for plausi-
bility.
22 -
Plaus.-Check Machine
Data, DS2
The rated motor parameters in data set 2 are checked for plausi-
bility.
23 -
Plaus.-Check Machine
Data, DS3
The rated motor parameters in data set 3 are checked for plausi-
bility.
24 -
Plaus.-Check Machine
Data, DS4
The rated motor parameters in data set 4 are checked for plausi-
bility.
30 -
Calculation and Para-
Ident., DS0
The auto set-up routine determines extended motor data via the
parameter identification feature, calculates depend-ent parameters
and stores the parameter values in all of the four data sets identi-
cally.
31 -
Calculation and Para-
Ident., DS1
Further motor data are measured, dependent pa-rameters are
calculated and the parameter values are saved in data set 1
32 -
Calculation and Para-
Ident., DS2
Further motor data are measured, dependent pa-rameters are
calculated and the parameter values are saved in data set 2
33 -
Calculation and Para-
Ident., DS3
Further motor data are measured, dependent pa-rameters are
calculated and the parameter values are saved in data set 3
34 -
Calculation and Para-
Ident., DS4
Further motor data are measured, dependent pa-rameters are
calculated and the parameter values are saved in data set 4
40 -
Para-Ident. Machine
Data only, DS0
Extended motor data are measured and saved identically in all
data sets. Other parameter values already set are maintained.
41 -
Para-Ident. Machine
Data only, DS1
Extended motor data are measured and saved data set 1. Other
parameter values already set are maintained.
42 -
Para-Ident. Machine
Data only, DS2
Extended motor data are measured and saved data set 2. Other
parameter values already set are maintained.
43 -
Para-Ident. Machine
Data only, DS3
Extended motor data are measured and saved data set 3.
44 -
Para-Ident. Machine
Data only, DS4
Extended motor data are measured and saved data set 4. Other
parameter values already set are maintained.
797 Setup Status
The individual steps of the auto set-up routine can be monitored and checked via parameter
SETUP
Status
797. The setup routine via the communication interface continuously updates the status pa-
rameter which can be read out via the interface.
Status messages
Message
Meaning
OK
Auto set-up routine has been carried out.
PC Phase 1
The plausibility check of the motor data is active.
PC Phase 2
The calculation of dependent parameters is active.
STO
The parameter identification demands enable on digital input STOA and
STOB.
Parameter identifica-
tion
The rated motor values are checked by the parameter identification feature.
Setup already active
The setup routine via the operator panel is being carried out.
No Release
No enable signal. The parameter identification demands enable on digital
input STOA and STOB.
Error
Error during the auto set-up routine.
Warning Phase Asym-
metry
The parameter identification feature diagnosed an unbalance during the
measurements in the three motor phases.
Setup not carried out
The setup is not carried out until now.
If a warning message is output or an error occurs during Setup, refer to chapter 6.2.5 “Warnings dur-
ing commissioning”.
109
Set-up via the Communication Interface 06/2013 Operating Instructions
