BONFIGLIOLI Agile User Manual

Parameter descriptions
Operation Mode Motor
Temp. 570
Function
0 -
Off
Motor temperature monitoring switched off.
1 -
Therm.-Contact, P204:
Warning only
Monitoring for temperature limit. A thermal overload is displayed via
the operator panel and parameter Warnings 269. For parameter
Thermal contact for P570 204, the digital input to which the ther-
mal contact is connected must be selected. In the factory setup,
multifunction input 2 can be used for connection of a thermal con-
tact (
Thermal contact for P570 204 is set to MFI2D). The input
signal must be digital. The evaluation (NPN/PNP) of the input signal
can be set via parameter Operation mode MFI2 562.
2 -
Therm.-Contact, P204:
Error Switch-Off
Monitoring for temperature limit. The frequency inverter is switched
off immediately if the motor is thermally overloaded. The error
switch-off is displayed by message F0400. For parameter
Thermal
contact for P570
204, the digital input to which the thermal contact
is connected must be selected. In the factory setup, multifunction
input 2 can be used for connection of a thermal contact (
Thermal
contact for P570
204 is set to MFI2D). The input signal must be
digital. The evaluation (NPN/PNP) of the input signal can be set via
parameter Operation mode MFI2 562.
3 -
Therm.-Contact, P204:
Err.Switch-Off 1 min
delayed
Monitoring for temperature limit. The frequency inverter is switched
off if the motor is thermally overloaded. The error switch-off is dis-
played by message F0400. The error switch-off is delayed by one
minute. For parameter
Thermal contact for P570 204, the digital
input to which the thermal contact
is connected must be selected. In
the factory setup, multifunction input 2 can be used for connection
of a thermal contact (
Thermal contact for P570 204 is set to
MFI2D). The input signal must be digital. The evaluation (NPN/PNP)
of the input signal can be set via parameter
Operation mode MFI2
562.
11 -
MPTC, MFI2: Warning
only
Monitoring for temperature limit. A thermal overload is displayed via
the operator panel and parameter Warnings 269. Multifunction
input 2 can be used as input for monitoring of a temperature value
with motor PTC (PTC as per DIN 44081). The input signal must be
analog.
12 -
MPTC, MFI2: Error
Switch-Off
Monitoring for temperature limit. The frequency inverter is switched
off immediately if the motor is thermally overloaded. The error
switch-off is displayed by message F0400. Multifunction input 2 can
be used as input for monitoring of a temperature value with motor
PTC (PTC as per DIN 44081). The input signal must be analog.
13 -
MPTC, MFI2: Err.Switch-
Off 1 min delayed
Monitoring for temperature limit. The frequency inverter is switched
off if the motor is thermally overloaded. The error switch-off is dis-
played by message F0400. The error switch-off is delayed by one
minute. Multifunction input 2 can be used as input for monitoring of
a temperature value with motor PTC (PTC as per DIN 44081). The
input signal must be analog.
21 - KTY, MFI2: Warning only
Temperature measurement. A thermal overload is displayed via the
operator panel and parameter Warnings 269. The warning is dis-
played as soon as the value of
Max. Temp. Motor Winding 617 is
reached. Multifunction input 2 can be reached as input for tempera-
ture measurement with a KTY measuring resistor (KTY84). The in-
put signal must be analog. Parameter
Winding temperature 226
shows the actual value.
138
Operating Instructions
Agile 06/2013 Error and warning behavior
