BONFIGLIOLI Agile User Manual

Options
Interference suppression class
Agile
size 3, AGL 402-19 (5.5 kW), AGL 402-21 (7.5 kW)
Installation measure
Agile 3
AGL402-19 (5.5 kW)
AGL402-21 (7.5 kW)
Without EMC input filter, without line choke
-
Without EMC input filter, with line choke 15 A or 25 A
Class C3
With footprint filter FTV003B-AGL
Class C1
With footprint filter FTV003B-AGL and line choke 25 A upstream on
mains input side
Class C1
With booktype filter FTV016A
Class C1
With booktype filter FTV016A and line choke 15 A upstream on mains
input side
Class C1
Interference suppression class
Agile
size 3, AGL 402-22 (9.2 kW)
Installation measure
Agile 3
AGL402-22 (9.2 kW)
Without EMC input filter, without line choke
-
Without EMC input filter, with line choke 15 A or 25 A
Class C3
With footprint filter FTV003B-AGL
Class C1
With footprint filter FTV003B-AGL and line choke 25 A upstream on
mains input side
Class C1
With booktype filter FTV016A
Class C1
With booktype filter FTV016A und Netzdrossel vor dem Filter
Class C1
Interference suppression class
Agile
size 3, AGL 402-23 (11 kW)
Installation measure
Agile 3
AGL402-23 (11 kW)
Without EMC input filter, without line choke
-
Without EMC input filter, with line choke 15 A or 25 A
Class C3
With footprint filter FTV003B-AGL
Class C1
With footprint filter FTV003B-AGL and line choke 25 A upstream on
mains input side
Class C1
With booktype filter FTV030A
Class C1
With booktype filter FTV030A and line choke 25 A upstream on mains
input side
Class C1
304
Operating Instructions
Agile 06/2013 Input filter
