BONFIGLIOLI Agile User Manual

Error protocol
Error environment
No.
Description
Function
350 Status of digital inputs
Decimally encoded status
− of the enable signal (STOA AND STOB)
− of the six digital inputs and
− of multifunction input 1 (if
Operation mode MFI1 452 = "3 -
digital NPN (active: 0 V)" or "4 - digital PNP (active: 24 V))" and
− of multifunction input 2 (if
Operation mode MFI2 562 =
"3 - digital NPN (active: 0 V)" or "4 - digital PNP (active: 24 V))".
351 Status of digital outputs
Decimally encoded status
− of digital output at terminal X12.5.
− of multifunction output at terminal X13.6 (if
Operation mode
MFO1 (X13.6)
550 = "1 - Digital MFO1D"
− of digital input/output at terminal X11.6 (if
Operation mode ter-
minal X11.6
558 = "1 - output OUT3D")
− of relay output at terminal X10
352 Time since release
Time of the error in hours (h), minutes (m) and seconds (s) after
enable signal:
hhhhh:mm:ss .
sec
/
10
sec
/
100
sec
/
1000
.
353
Heat sink temperature
Measured heat sink temperature.
354 Inside temperature Measured inside temperature.
355 Controller status
The reference value signal is limited by the controller coded in the
controller status.
356 Warning status The warning messages coded in warning status.
357 Int. value 1 Software service parameter.
358 Int. value 2 Software service parameter.
359 Long value 1 Software service parameter.
360 Long value 2 Software service parameter.
367
Application Warning
State
The application warnings coded in warning status.
361 Checksum
The
Checksum 361 parameter shows whether the storage of the error environment was free of errors
(OK) or incomplete (NOK).
Error environment
No. Description Function
361 Checksum Check protocol of the error environment.
330
Operating Instructions
Agile 06/2013 Error environment
