Commissioning
WARNING
The key RUN starts the drive, if the enable signals at digital inputs STOA (terminal
X11.3) and STOB (terminal X13.3) are switched on. The start or stop of the drive is
possible, even if menu Poti F is currently not selected. For example the start of the drive
is possible if menu PARA for parameter settings or menu ACTUAL for actual value dis-
play is selected.
Display of drive status:
The drive rotates at the reference frequency value. The reference frequency
value is the sum of Reference frequency source 1 475 and Reference frequency
492.
The drive is stopped. The alternating display shows the reference frequency
value and the message STOP.
The selection Poti F is only available if the parameter Local/Remote 412 was set like
described above.
57
Operator panel 06/2013 Operating Instructions
