BONFIGLIOLI Agile User Manual

Commissioning
Energy saving
Chapter
Switch off
display
Set a time in P1510. If no key is pressed on the operator panel during
this time, the display will be switched off.
8
Switch off
functions
Via P1511, select which functions are to be switched off: Operator
panel, digital inputs and outputs, communication or fan. The frequency
inverter switches the functions off thus reducing power consumption if
enable is switched off via digital inputs STOA and STOB.
8
Energy sav-
ing function
For P30, “110 - IM sensor-less control (SLC)” or “410 - IM: sensor-less
field-oriented control” must be selected.
Via P1550, select if the possible energy savings are to be determined
automatically or specified via an entered value (P1551).
Via P1551, select which digital input or logic signal is to be used for
starting the energy saving function.
8.1
Quadratic V/f
characteristic
For load behavior with torque increasing quadratically to speed (e.g.
fan). For control according to V/f characteristic. For P30, "110 - IM
sensor-less control (SLC)" must be selected.
Via P606, set the characteristic to "2 - quadratic".
Set up the V/f characteristic using parameters 600 … 604.
8.2
Other
E.g. temperature-controlled fans, automatic switch frequency change-
over, energy-optimized braking.
8.4
Service
Chapter
Service inter-
val
The time remaining until service of DC link (P1530) and fan (P1531)
can be displayed.
10.3
If the time is expired, a message in P1533
or a warning will be output. The reaction
can be set up.
DC-Link:
Fan:
P1534
P1535
10.3.1
10.3.2
Test functions
Chapter
For finding errors and defects at the frequency inverter, sensors, the
load and the electrical connections.
Earth fault/
short circuit
test
Test for earth fault or short-circuit with DC link potential.
7.2.3.1
Load test
Test of IGBTs, the load (e.g. for short circuit), current measurement
and for broken cables.
7.2.3.2
Start test
With opera-
tor panel
Switch on enable at inputs STOA and STOB.
Select menu item "Test" in "Local" menu.
Select test 1. Comply with the instructions in chapter
7.2.3.1 “Earth fault and short circuit test (Test 1)
”.
Then, select test 2.
7.2.3.3
With PC
software
VPlus
Via P1540, select "11 - Start Test 1" or "12 - Start
Test 2".
7.2.3.4
Automatic
test
Via P1542, select which test is to be started each time after an error
switch-off.
7.2.3.5
Kapitel
Test of fan
The function of the fans is tested
Start test
With opera-
tor panel
Switch on enable at inputs STOA and STOB.
Select menu item "Test" in “Local” menu.
Select Test 3. Press ENT. The fans must rotate.
Press ESC.
7.2.3.6
97
