About this product 25/188

3 842 564 874/2021-04, MIT: ActiveMover, Bosch Rexroth AG

Fig. 9:

CBD

557 186-09

Section module with open electronics box

Electronics box

Printed circuit board

(coil driver)

Printed circuit board

(gateway)

Printed circuit board

(coil driver)
