■ Error code 60 (C), 61 (M), 62 (Y), 63 (K)
Toner cartridge is at the end of life. (The counter value of the develop roller reaches the end of
life, or the toner sensor detects toner empty.)
<User Check>
- Gently shake the toner cartridge of the appropriate color from side to side and install it again.
- Replace the toner cartridge of the appropriate color.
Replace Toner
Open the Top Cover, replace Toner Cartridge. Cyan (C).
Replace Toner
Open the Top Cover, replace Toner Cartridge. Magenta (M).
Replace Toner
Open the Top Cover, replace Toner Cartridge. Yellow (Y).
Replace Toner
Open the Top Cover, replace Toner Cartridge. Black (K).
Step Cause Remedy
1 HVPS control PCB failure Replace the HVPS control PCB ASSY.
2 Engine PCB failure Replace the engine PCB ASSY.
3 Main PCB failure Replace the main PCB ASSY.
4 Harness connection failure of
toner/new sensor PCB ASSY
Check the sensor performance following
the procedure described in “Function code
32”. If any problem occurs, check the
harness connection of the toner/new
sensor PCB ASSY of the appropriate
color, then reconnect it.
5 Toner/new sensor PCB failure Replace the toner/new sensor PCB ASSY.
To Next Page
