5-148

Confidential

8.61 Develop Drive Motor

(1) Remove the three Screw bind M3x4, and then remove the Develop drive motor from the

Drum develop drive unit.

Fig. 5-177

Screw bind M3x4

Drum develop drive unit

Develop drive motor
