5-118
Confidential
8.48 FFC Harness:MAIN-LED CTL
(1) Insert the two “A” of the removed Sub frame ASSY into the two “B” of the Main body and
close it as shown in the figure below.
Fig. 5-134
Sub frame ASSY
“A”
“A”
Main body
“B”
“B”
1a
1b
