5-196
Confidential
8.86 Waste Toner Sensor
(1) Release the two Hooks to remove the Wire cover 2 from the Side frame R.
Fig. 5-257
Fig. 5-258
Assembling Note:
When assembling the Wire cover 2, make sure to pass the Waste toner harness ASSY
through the “A” before assembling it.
Wire cover 2
Hook
Side frame R
Side frame R
“A”
Waste toner harness ASSY
