5-12
Confidential
6. HARNESS ROUTING
1 Joint Cover Sub ASSY
Joint cover sub ASSY
Hook
A
Sub frame ASSY
LED head control
PCB ASSY
Front
LED main FFC film
A
Side frame L
Slit
Front
Main PCB ASSY
Front
Side frame L
LED head control
PCB ASSY
A
