Brother MFC-9010CN Service Manual

3-58
Confidential
3.2 Double Feeding
<User Check>
- Check if the paper is loaded into the paper tray correctly.
- Turn over the stack of paper in the paper tray, or try rotating the paper 180° in the paper tray.
- Check if the thickness of the paper is 60 to 105 g/m
2
.
- Set out papers and reload them into the paper tray.
3.3 Paper Jam
<User Check>
- Check if the paper is loaded into the paper tray correctly.
- Turn over the stack of paper in the paper tray, or try rotating the paper 180° in the paper tray.
- Check if the thickness of the paper is 60 to 105 g/m
2
.
■ Paper jam in the paper tray and front section
Step Cause Check
Result
Remedy
1 Separation pad or
separation roller
worn out
Is the surface of the
separation pad or
separation roller worn out?
Yes Replace the paper
feeding kit.
Step Cause Check
Result
Remedy
1
Foreign object
around front section
Is there a foreign object
around the front section?
Yes Remove the foreign
object.
2 Belt unit
malfunction
Does the belt unit move
correctly?
No Replace the belt unit.
3 Registration front
actuator catching
on some position
Does the registration
front actuator move
smoothly?
No Re-assemble the
registration front
actuator.
4 Registration rear
actuator catching
on some position
Does the registration
rear actuator move
smoothly?
No Re-assemble the
registration rear
actuator.
5 Registration front/
rear sensor PCB
failure
Does the registration
front/rear sensor move
smoothly?
(Check it following the
procedure described in
“Function code 32”.)
No Replace the
registration front/rear
sensor PCB ASSY.
