5-164
Confidential
8.69 Fuser/Eject Drive Motor
(1) Remove the Taptite bind B M4x12 screw and Taptite cup S M3x6 SR screw, and then
remove the Fuser/Eject drive motor from the Fuser eject drive ASSY.
Fig. 5-205
Harness routing: Refer to “ Fuser/Eject Drive Motor, Fuser/Eject Drive Motor Sensor PCB
ASSY.”
Fuser eject drive ASSY
Taptite cup S M3x6 SR
Taptite bind B M4x12
Fuser/Eject drive motor
