5-61

Confidential

8.14 ADF Cover ASSY

(1) Place the ADF unit the right way up.

(2) Release the two Pins on both sides of the ADF cover ASSY to remove it while the ADF

cover ASSY being opened.

Fig. 5-45

ADF cover ASSY

Pin

Pin

ADF unit

2c

2b

2a

2a

2a
