8.25 Control Panel Cover ASSY

(1) Release the eight Hooks to remove the Control panel cover ASSY from the Document

scanner unit.

Fig. 5-67

Hook

Document scanner unit

Hook

Hook

Hook

Control panel cover ASSY
