5-143
Confidential
8.60 Drum Develop Drive Unit
(1) Place the Main body upright as shown in the figure below.
Fig. 5-167
(2) Release the Hook to remove the Line holder front from the Develop drive plate ASSY.
Fig. 5-168
Main body
Hook
Develop drive plate ASSY
Line holder front
Side frame L
