5-177
Confidential
8.78 Belt Drive ASSY
(1) Remove the three Taptite pan (washer) B M4x12DA screws, and then remove the Belt
drive ASSY from the Side frame L.
Fig. 5-225
Harness routing: Refer to “ Belt Drive ASSY.”
Taptite pan (washer)
Side frame L
Belt drive ASSY
B M4x12DA
