Brother MFC-9010CN Service Manual

7-39
Confidential
1.4.20 Frame pattern print (Function code 69)
<Function>
This function allows you to print the external periphery frame pattern on a sheet and check if
there is print deflection and/or loss.
<Operating procedure>
(1) Load Letter-size paper on the paper tray.
(2) Press the 6 and 9 buttons in this order in the initial state of the maintenance mode.
“PRINTING” is displayed on the LCD, and the frame pattern (see the figure below) is
printed on a sheet.
(3) When the Stop/Exit button is pressed, the machine beeps for one second and returns to
the initial state of the maintenance mode
When an error message is displayed on the LCD, take the measures described in the table below.
* # indicates the toner color (K, Y, M, or C) of which cartridge became empty.
Note:
When printing fails, a relevant error is displayed on the LCD. After the error is solved and
the
Start/Black button is pressed, the machine automatically goes back to the
re-executable state, and “WAKU SX” is displayed on the LCD. When the
OK button is
pressed, “PRINTING” is displayed on the LCD, and the frame pattern is printed on a sheet.
Error message Measure
TONER EMPTY # * Replace the empty toner cartridge and press the Start/Black
button to clear the error. Perform the frame pattern print
again.
Cover is Open Close the top cover.
No Paper Replenish paper, and press the Start/Black button to clear
the error.
Jam Tray1 Remove the jammed paper, and press the Start/Black
button to clear the error.
Jam Rear Remove the jammed paper, and press the Start/Black
button to clear the error.
