Brother MFC-9010CN Service Manual

5-11
Confidential
■ PF drive
<Development view>
<Layout view>
* Inside of side frame L
<Name of gears>
* These parts are subject to change without notice.
40 LR0910 Hook spring 46 LU5089 Planetary clutch ASSY
41 LU5093 LM hook B 47 LR0910 Hook spring
42 LU5094 LM hook C 48 LU5105 Worm Z33
43 LU5095
P/P gear 26 sector 49 LU5106 Bevel gear Z17G
44 LU6447
P/P gear 26 sector spring 50 LR0301 Bevel gear Z23G
45 LU5088 LM hook A
50
49
48
46
47
45
40
41
44
43
42
Side frame L
<Front>
41
41
39
39
40
40
38
38
44
44
43
43
42
42
45
45
46
46
48
48
47
47
43
41
42
40
46
45
44
47
48
50
49
