4-16
Confidential
(11) Assemble the Back cover stopper L and Back cover stopper R to the Main body.
Fig. 4-23
(12) Close the Back cover.
Fig. 4-24
(13) After replacing the Fuser unit, reset the counter. (Refer to “2.1 Resetting the Periodical
Maintenance Parts Life” in Chapter7.)
Hook
Back cover stopper L
Back cover stopper R
Main body
<Back side>
Back cover
Back cover
<Back side>
