Brother MFC-9010CN Service Manual

5-4
Confidential
USB direct interface relay PCB
ASSY or panel ground plate 2
Taptite bind B M3x8 1 0.40±0.05 (4±0.5)
FG harness Taptite bind B M3x8 1 0.40±0.05 (4±0.5)
USB holder Taptite bind B M3x8 2 0.40±0.05 (4±0.5)
Front cover Taptite bind B M4x12 2 0.90±0.10 (9±1)
LED FG harness ASSY Taptite cup S M3x6 SR 1 0.50±0.10 (5±1)
Inner chute ASSY 2 Taptite bind B M4x12 2 0.90±0.10 (9±1)
Arm guide L Taptite bind B M4x12 2 0.90±0.10 (9±1)
TC harness cover 2 Taptite bind B M4x12 2 0.90±0.10 (9±1)
Arm guide R Taptite bind B M4x12 2 0.90±0.10 (9±1)
Back up plate Taptite cup B M3x8 6 0.40±0.05 (4±0.5)
Taptite cup S M3x6 SR 2 0.50±0.15 (5±1.5)
Sub frame ASSY Taptite bind B M4x12 4 0.90±0.10 (9±1)
Inner chute ASSY 1 Taptite bind B M4x12 5 0.90±0.10 (9±1)
LED PCB cover Taptite cup S M3x6 SR 4 0.50±0.10 (5±1))
Insulation sheet B
LED head control PCB ASSY Taptite cup S M3x6 SR 4 0.50±0.10 (5±1)
Develop release motor ASSY Taptite bind S M3x5 1 0.70±0.10 (7±1)
Main PCB ASSY Taptite cup S M3x6 SR 4 0.50±0.10 (5±1)
Engine PCB ASSY Taptite cup S M3x6 SR 2 0.80±0.10 (8±1)
(Front side)
2 0.50±0.10 (5±1)
(Back side)
Main PCB shield plate Taptite cup S M3x6 SR 3 0.80±0.10 (8±1)
Taptite bind B M4x12 1 0.90±0.10 (9±1)
Engine shield plate Taptite bind B M4x12 1 0.90±0.10 (9±1)
Taptite cup S M3x6 SR 1 0.80±0.10 (8±1)
Develop drive plate ASSY Taptite cup S M3x6 SR 2 0.80±0.10 (8±1)
Taptite bind B M4x12 2 0.90±0.10 (9±1)
Under bar Taptite bind B M4x12 4 0.90±0.10 (9±1)
Under bar earth plate Taptite cup S M3x6 SR 1 0.80±0.10 (8±1)
Drum develop drive unit Taptite bind B M4x12 3 0.90±0.10 (9±1)
Taptite cup S M3x6 SR 2 0.80±0.10 (8±1)
Develop drive motor Screw bind M3x4 3 0.50±0.05 (5±0.5)
Paper feed motor ASSY Screw bind M3x4 3 0.50±0.05 (5±0.5)
Paper feed unit Taptite cup S M3x6 SR 3 0.80±0.10 (8±1)
Shoulder screw 2 0.80±0.10 (8±1)
PF upper cover ASSY Taptite cup B M3x10 2 0.60±0.10 (6±1)
Registration front/rear sensor
PCB ASSY
Taptite cup B M3x8 1 0.55±0.05 (5.5±0.5)
Front chute ASSY Taptite cup B M3x10 2 0.60±0.10 (6±1)
Cleaner PF gear cover Taptite bind B M4x12 5 0.90±0.10 (9±1)
Location of screw Screw type Q'ty
Tightening torque
N
·m (kgf·cm)
