EM2: MOLYKOTE EM-D110 (2 mm dia. ball)

PG1: MOLYKOTE PG-661 (W) (1 mm dia. ball)

EM2

Paper tray

2 places (one for each to the right and left)

PG1

1 place

LED ASSY
