5-24
Confidential
20 ADF Unit
<A view>
ADF motor
Hook
ADF unit
ADF sensor
PCB ASSY
Hole
Hook
ADF motor
ADF unit
Document scanner unit
Hole
Hook
ADF sensor PCB ASSY
Front
Joint cover sub ASSY
TC harness cover 2
Hook
Main PCB shield plate
Side frame L
A view
