5-36
Confidential
Fig. 5-5
Assembling Note:
When assembling the Roller holder ASSY onto the Paper feed unit, make sure to align the
Shaft of the Roller holder ASSY with the Hole of the Paper feed unit, and then insert it into
the Hole.
Roller holder ASSY
Paper feed unit
Paper feed unit
Shaft
Hole
