5-38
Confidential
Fig. 5-8
Assembling Note:
Make sure to assemble the Separation pad ASSY in a way that the “A” of the Separation
pad ASSY fits into the “B” of the Pad spring.
Separation pad ASSY
“A”
Pad spring
“B”
