5-44
Confidential
(3) Remove the Paper eject front actuator spring from the Paper eject front actuator.
Fig. 5-18
Fig. 5-19
Assembling Note:
- When assembling the Paper eject front actuator, assemble the Paper eject front actuator
spring as shown in the figure below.
- Check that the Paper eject front actuator is moved smoothly.
Paper eject front actuator
Paper eject front actuator spring
Paper eject front actuator
Fuser cover
Paper eject front
actuator spring
