5-53
Confidential
Fig. 5-31
Assembling Note:
When assembling the Side cover R ASSY onto the Main body, make sure to push the three
Hooks of the Front cover into the three “A” of the Side cover R ASSY.
Side cover R ASSY
Front cover
“A”
Hook
<Right side>
