5-57

Confidential

(8) Remove the Pull arm L, Pull arm spring ADF L, Pull arm R and Pull arm spring ADF R

from the Pull arm guide.

Fig. 5-38

Pull arm guide

Pull arm L

Pull arm R

Pull arm spring ADF L

Pull arm spring ADF R

Hook

Hook

Pull arm guide
