5-82
Confidential
(3) Release the two Hooks to remove the Backlight guide from the Panel cover generic.
Fig. 5-74
(4) Release the two Hooks to remove the LCD from the Backlight guide.
Fig. 5-75
Hook
Panel cover generic
Hook
Backlight guide
Hook
Backlight guide
LCD
Hook
