5-88
Confidential
(4) Remove the FB lock lever L from the Joint cover sub ASSY.
Fig. 5-83
(5) Remove the FB lock spring from the spring hook and FB lock lever R of the joint cover sub
ASSY.
Fig. 5-84
Joint cover sub ASSY
FB lock lever L
FB lock lever R
FB lock spring
Spring hook
Joint cover sub ASSY
