5-123
Confidential
(3) Remove the four Taptite cup S M3x6 SR screws, and then remove the LED head control
PCB ASSY from the Sub frame ASSY.
Fig. 5-141
Taptite cup S M3x6 SR
Taptite cup S M3x6 SR
LED head control PCB ASSY
Sub frame ASSY
