5-159
Confidential
(4) Remove the Friction spring from the Cleaner PF gear cover.
Fig. 5-195
(5) Remove the Pick-up sector gear spring from the Side frame L.
Fig. 5-196
Cleaner PF gear cover
Friction spring
Side frame L
Pick-up sector gear spring
